Anchor Base 500, 700, 1000 Series Light Poles | Eos Series

Model No

Shaft Length
(Ft)

15

20

25

30

35

40

Model No

Bolt Circle
(In)

11-12

11-12

11-12

11-12

11-12

11-12

Model No

Bolt Size
(In)

1x36 + 4 6T

1x36 + 4 6T

1x36 + 4 6T

1x36 + 4 6T

1x36 + 4 6T

1x36 + 4 6T

Model No

Tip Diameter
(In)

5.3

5.3

5.3

5.3

5.3

5.3

Model No

Butt Diameter
(In)

8.2

8.3

8.4

8.6

8.7

8.8

Model No

Nominal Pole Weight
(lbs)

40

55

71

93

125

131

Model No

EPA

10

10

10

10

10

10

Shaft Length
(Ft)

Bolt Circle
(In)

Bolt Size
(In)

Tip Diameter
(In)

Butt Diameter
(In)

Nominal Pole Weight
(lbs)

EPA

15

11-12

1x36 + 4 6T

5.3

8.2

40

10

20

11-12

1x36 + 4 6T

5.3

8.3

55

10

25

11-12

1x36 + 4 6T

5.3

8.4

71

10

30

11-12

1x36 + 4 6T

5.3

8.6

93

10

35

11-12

1x36 + 4 6T

5.3

8.7

125

10

40

11-12

1x36 + 4 6T

5.3

8.8

131

10

A = Anchor Base

Notes:
* EPA recommendations are calculated per AASHTO standards and include a 30% gust factor.
