100 MPH Anchor Base
Series Data & Options
EPA Rating: 3
Max Wind Speed: 100 MPH
Shroud Material: Urethane
Pole Material: Fiberglass
Anchor Base:
Mounting Options:
- T4 - 2 3/8" x 4 5/8" Tenon
- T5 - 3" x 4 5/8" Tenon
- T7 - Custom Tenon
- S8 - Reinforced Side Mount
- S9 - Reinforced Side Mount (predrilled)
Color Options:
- BLK - Black
- BR - Bronze
- WH - White
- GR - Gray
- CM - Color Match
Hand Hole Options:
- H0 - No Handhole
- H2 - 2 1/2" x 5" Handhole
GFI Options:
- GFI0 - No GFI
- GFI - Standard
- GFIU - In-Use
Shroud Options:
- 0SH - No Shroud
- 2SH - Two Piece
Model Specifications
| Model No | Shaft Length | Tip OD | Ground Level OD | Bolt Size | Bolt Circle Diameter | Nominal Pole Weight | |
|---|---|---|---|---|---|---|---|
| st-a310 | 10 ft | 5.3" | 5.6" | 3/4x15 + 3 4T | 8-9.5" | 17 lbs | Create Cut Sheet |
| st-a312 | 12 ft | 5.3" | 5.6" | 3/4x15 + 3 4T | 8-9.5" | 21 lbs | Create Cut Sheet |
| st-a314 | 14 ft | 5.3" | 5.6" | 3/4x15 + 3 4T | 8-9.5" | 24 lbs | Create Cut Sheet |
| st-a316 | 16 ft | 5.3" | 5.6" | 3/4x15 + 3 4T | 8-9.5" | 32 lbs | Create Cut Sheet |
| st-a318 | 18 ft | 5.3" | 6" | 3/4x15 + 3 4T | 8-9.5" | 36 lbs | Create Cut Sheet |
| st-a320 | 20 ft | 5.3" | 6" | 3/4x15 + 3 4T | 8-9.5" | 45 lbs | Create Cut Sheet |
| st-a322 | 22 ft | 5.3" | 6" | 3/4x15 + 3 4T | 8-9.5" | 52 lbs | Create Cut Sheet |
| st-a324 | 24 ft | 5.3" | 6" | 3/4x15 + 3 4T | 8-9.5" | 57 lbs | Create Cut Sheet |
| st-a325 | 25 ft | 5.3" | 6" | 3/4x15 + 3 4T | 8-9.5" | 59 lbs | Create Cut Sheet |
